Internal Compression ASU

The liquid oxygen is pressurized to the required pressure in the cold box through liquid oxygen pumps, and then it exchanges heat with the pressurized air pressurized by the booster compressor through the medium pressure heat exchanger, then gasified, and finally the gas is sent to the users. The pressure of oxygen and nitrogen generated can reach 8.5MPa, which can meet the requirement of diverse pressures of gaseous oxygen and nitrogen in chemical industry.

Product Description

The liquid oxygen is pressurized to the required pressure in the cold box through liquid oxygen pumps, and then it exchanges heat with the pressurized air pressurized by the booster compressor through the medium pressure heat exchanger, then gasified, and finally the gas is sent to the users. The pressure of oxygen and nitrogen generated can reach 8.5MPa, which can meet the requirement of diverse pressures of gaseous oxygen and nitrogen in chemical industry.

Advantages:

1. The patented technology is mature and the process is optimized.

2. The operation is stable and safe.

3. Extremely high level production and installation quality.

4. Excellent pre- and after-sales services.

  • Henan Kaiyuan Air Separation Group Co. Ltd.
  • Henan Kaiyuan Air Separation Group Co. Ltd.
  • Henan Kaiyuan Air Separation Group Co. Ltd.
  • Henan Kaiyuan Air Separation Group Co. Ltd.
  • Henan Kaiyuan Air Separation Group Co. Ltd.

Parameter

--Sample Models
Project name Year Location Application field Operating conditions Oxygen yield (optional LOX yield) O2 purity (upgradable) Gas Oxygen Pressure Nitrogen  yield(optional LN yield) Nitrogen  purity Gas Nitrogen Pressure (compressor inlet/outlet) Argon yield (Nm3/h) Argon purity
KDON-6000
/13000
2008 XinJiang chemical Design 6000 nm3/h or 200TPD 99.6%O2 4.0 MPa 13000 nm3/h or 390TPD ≤10PPmO2 10kpa   2PPmO2
KDONAr-5000
/550
/150
2006 Turkey metallurgy Design 3750 nm3/h or 125TPD 2.5 MPa 550 nm3/h or 16.5TPD 10kpa/1.5MPa 150 nm3/h or 6.5TPD
KDONAr-6000
/6000
/120
2007 Libya metallurgy Design 6000 nm3/h or 200TPD 4.0 MPa 6000 nm3/h or 180TPD 10kpa /2.0MPa 300 nm3/h or 13TPD
KDONAr-11500
/560
/355
2011 Russia chemical Design 10000nm3/h or 340TPD (1500nm3/h or 50TPD) 2.5MPa 400nm3/h or 12TPD (160nm3/h or 5TPD) 10kpa 355nm3/h or 15TPD
KDONAr-31500
/30000
/1100
2008 HeBei metallurgy   30000nm3/h or 1000TPD (1500nm3/h or 50TPD) 3.0Mpa 30000nm3/h or 900TPD 10kpa /2.4MPa 1100nm3/h or 45TPD
KDONAr-13100
/6500
/460
2012 ShanDong metallurgy Design 11600nm3/h or 395TPD (1500nm3/h or 50TPD) 1.8Mpa 6000nm3/h or 180TPD (500nm3/h or 15TPD) 10kpa 460nm3/h or 19.5TPD
Condition1 11000nm3/h or 375TPD (2000nm3/h or 65TPD) 6000nm3/h or 180TPD 10kpa /1.8MPa
KDONAr-9000
/10500
/280
2018 QingHai chemical Design 8200nm3/h or 280TPD (800nm3/h or 27TPD) 8.25 MPa 8900nm3/h or 265TPD (1600nm3/h or 48TPD) 10kpa /0.9MPa 280nm3/h or 12TPD
Condition1 4300nm3/h or 145TPD (2900nm3/h or 100TPD) 8900nm3/h or 265TPD 220nm3/h or 9.5TPD
KDONAr-60000
/74000
/1560
2019 JiangSu metallurgy Design 55000nm3/h or 1882TPD (5000nm3/h or 170TPD) 1.0 MPa 70000nm3/h or 2100TPD (4000nm3/h or 120TPD)   1560nm3/h or 65TPD
Condition1 60000nm3/h or 2055TPD (2300nm3/h or 75TPD) 77000nm3/h or 2310TPD (6200nm3/h or 185TPD) 1560nm3/h or 65TPD
Condition2 48000nm3/h or 1645TPD (5500nm3/h or 188TPD) 56000nm3/h or 1680TPD (4000nm3/h or 120TPD) 1380nm3/h or 60TPD
